Positioning heavy cargo on a trailer requires precision to avoid accidents, fines, or delays. Improper weight distribution can destabilize the rig, damage infrastructure, or violate DOT regulations. To ensure a safe and compliant haul, keep the center of gravity low, distribute weight evenly, and adhere to state-specific rules. This clear guide helps you position heavy cargo correctly, prevent issues, and save time. Read on, apply our tips, and haul confidently!
Heavy cargo exceeds 80,000 pounds gross weight or axle limits (e.g., 12,000 pounds on steer axle, 34,000 on tandem). Correct positioning ensures vehicle stability, protects roads and bridges, and passes DOT inspections.
Mistakes like axle overloading or high center of gravity can lead to fines ($100–$5,000+), trip halts, or cargo damage. Services like omnipermits.com simplify permit applications, but accurate load placement is your responsibility. For related guidance, see How to properly load oversized cargo onto a trailer.
Tip. Photograph the positioned load to document compliance for DOT checks.
The goal is to keep the center of gravity low and within 2 inches of the trailer’s centerline. Distribute weight evenly across axles to avoid overloading. Standard axle limits are: steer axle (12,000 pounds, up to 13,000 with reinforced tires), drive axles (34,000 pounds), and trailer tandem/tridem (34,000–60,000 pounds, depending on configuration).
Always verify compliance with the Federal Bridge Formula (W = 500 × [(L × N) / (N - 1) + 12N + 36]), where W is max weight, L is axle spacing, and N is axle count. Check state regulations via DOT websites or omnipermits.com—states like Illinois and Pennsylvania enforce strict axle limits.
Tip. Use online bridge formula calculators to confirm weight distribution before applying for permits.
Uniform loads (e.g., steel coils): Place centrally along the trailer’s length and width for balance.
Long loads (e.g., beams, pipes): Position end-to-end, alternating to center the weight.
Heavy machinery (e.g., excavators): Place main mass over axles, with buckets/arms facing rear to reduce steer axle load.
Asymmetric loads: Position heavier parts near the center, using wooden dunnage for leveling.
Use lowboy or RGN trailers for low center of gravity. Concentrated loads (e.g., presses) may need extra axles to spread weight. Secure with anti-slip mats and FMCSA-compliant tie-downs.
Tip. Consult load distribution charts or omnipermits.com for complex cargos to optimize placement.
Weigh the loaded trailer on certified CAT scales to verify axle loads. Secure cargo with at least four tie-downs rated for 50% of the load’s weight, using FMCSA-approved chains, straps, or edge protectors. Ensure ground clearance is at least 5 inches and total height doesn’t exceed 13’6” without a permit.
For rear overhang >4 feet, attach red/orange flags (18×18 inches) by day or red lights (visible at 500 ft/150 m) at night, plus an “OVERSIZE LOAD” sign. Photograph the secured load for DOT inspection proof.
Tip. Verify tire load ratings match axle weights to prevent blowouts or fines.
The Federal Bridge Formula (W = 500 × [(L × N) / (N - 1) + 12N + 36]) sets max weight for axle groups. For example, three axles spaced 20 feet apart can carry ~42,000 pounds without a permit. Exceeding this requires an overweight permit. States like Michigan or Ohio strictly enforce the formula. Calculate it beforehand using online tools or omnipermits.com for accuracy.
Tip. Measure axle spacing with a laser distance meter to ensure precise formula inputs.
Uneven weight: Overloaded axles trigger out-of-service orders—use scales to balance loads.
No permit: Heavy loads without an overweight permit face fines and delays.
Weak tie-downs: Angles <45° or uncertified straps risk load shifts—use FMCSA-compliant gear.
High center of gravity: Causes tipping—keep heavy parts low and centered.
Unmarked overhang: Missing flags/lights leads to fines, especially at night.
Tip. Pre-plan routes with Hammer or Trucker Path to avoid weight-restricted bridges or roads.
Choose the right trailer. Lowboy or RGN trailers lower the center of gravity for heavy loads.
Weigh after loading. Use CAT scales to confirm axle and gross weights match the permit.
Check state laws. Illinois and Ohio have strict bridge rules—verify via DOT or omnipermits.com.
Log data. Record weights, dimensions, and tie-down photos in an ELD for inspections.
Hire professionals. For complex loads, omnipermits.com can handle calculations and permits.
Train team. Ensure drivers and operators know FMCSA and state standards.
Plan escorts. Loads >80,000 pounds often need pilot cars—book via DAT Load Board or omnipermits.com.
Use apps. Hammer or Trucker Path maps weight-compliant routes.
Carry spares. Stock extra chains, straps, and flags/lights for quick fixes.
Verify tires. Ensure tire load ratings (e.g., index 144 for 34,000-pound tandems) support axle weights.
Route planning. Use DOT maps or apps to avoid low bridges or weight-restricted zones.
Documentation. Store load photos in your ELD for quick inspection access.
With proper positioning, your heavy cargo will be safe and compliant. Weigh accurately, secure reliably, and haul without fines!
